5.3

Electrical Specifications

5.3.1

Input and Output Ratings

Model Chart for 36/48V version
Model Name
AC-M2 36/48V 500A+500A
5.3.2

Signal: Inputs and Outputs

Digital Inputs
Analog Inputs
Digital Outputs (ON/OFF)
Driver Outputs (PWM)
Motor Speed Sensor Inputs
Refer to following tables for a complete AC-M2 controller K1 and K2 connectors pin-out.
Pin Name
1 KEY SWITCH IN
2 DIGITAL IN 1
3 DIGITAL IN 2
4 DIGITAL IN 3
5 DIGITAL IN 4
6 DIGITAL IN 5
7 DIGITAL IN 6
8 DIGITAL OUT 1
9 COIL RETURN
10 RS-232 RX
11 RS-232 TX
12 DIGITAL IN 7
13 DIGITAL IN 8
14 LIN IN/OUT
15 CAN-H
16 DRIVER OUT 1
17 DRIVER OUT 2
18 I/O GROUND
19 DIGITAL OUT 2
20 DRIVER OUT 3
21 +12V OUT
Page 53/72
W11E | Operation manual
AC Inverter 1
Max Arms (2')
500 A
rms
K1 connector pin-out for AC-M2 SPECIFICATIONS
I/O
Supply Input Rated battery +25/-30%, 6Amax
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Output
Supply Output
Com Input
Com Output
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Digital Input 4mA pull-up, VL<=1V, VH>=3,5V
Com Input/Output
Com Input/Output
PWM Output
PWM Output
-
Digital Output
PWM Output
Supply Output
AC Inverter 2
Max Arms(2')
500 A
rms
4 (A+B Channels)
Specification
Low side 0,5A
High side 5A max
-
-
12mA pull-up
CAN-bus
Low side 2A
Low side 1,5A
-
Low side 1,5A
Low side 1,5A (*)
12V 250mAmax
Max Power (2')
at 48V
27.7 kVA + 27.7 kVA
17
6
2
3
Typical Function
Positive supply of the control
section of the AC-M2
TO BE ASSIGNED
TO BE ASSIGNED
TO BE ASSIGNED
TO BE ASSIGNED
TO BE ASSIGNED
TO BE ASSIGNED
TO BE ASSIGNED
Positive common
Serial port
Serial port
TO BE ASSIGNED
TO BE ASSIGNED
LIN display connection
CAN H (No internal
termination resistor)
TO BE ASSIGNED
TO BE ASSIGNED
Negative logic supply
TO BE ASSIGNED
TO BE ASSIGNED
12V supply
