2. GENERAL INFORMATION & OPERATING INSTRUCTIONS
2.1

Main components

The W11E is a four-wheel drive mini loader. It contains:
• Hydraulic motor
• Travel motor
• Multi-function operating handle
• 12 volt electrical system
• 51.1V400Ah lithium battery
Travel motor
Drive axle
Brake system
Wheels and tires
Electrical System
Quick disassembly device
Seat
Battery charger
Multi-function joystick
Parking brake
Pedal
Page 10/72
W11E | Operation manual
The loader is equipped with a powerful mobile motor that is certified by the
manufacturer to meet the job requirements and environmental requirements for
zero emissions.
The rear axle of the W11E is driven by the travel motor and then transmitted by
the drive shaft to the front drive axle.
This wheel loader brakes on the front axle and driving engine by pressing the
brake pedal.
The loader tires are pneumatic and are able to travel smoothly and effectively
maximize traction. Remember to check the pressure on your pneumatic tires
regularly.
Unbalanced tire pressure will not only increase tire wear, but also reduce traction
performance.
W11E tire model: 26x12-12AS Tire pressure: 3.0bar
The loader uses a 12 volt, automatic type, negative ground electrical system. The
system includes a 51.1V400Ah lithium battery (see battery instruction manual for
specific parameters), ignition switch, two headlights, amber flash, direction lights,
taillights, speakers, various meters and other circuits.
The attachment of the attachment is controlled by a multi-way valve for quick
assembly and disassembly.
The seat of the loader is equipped with a seat belt and can be adjusted back and
forth. The seat rating is EM8 (optional).
The loader is equipped with an integrated 220V battery charger with charging
indicator. Max. loading time 6 hours
The joystick is located to the right of the driver's position. As a standard, the
switch on the device can control the gear position of the loader. There are 3 gear
positions: forward gear, neutral gear and reverse gear, and reset button. The
handle can also control two multi-way valves, so that lifting and tilting can be
performed separately or in combination.
The electric driving motor is equipped with a parking brake drum. After the
vehicle stops for a few seconds, the electronic control motor is powered off, and
the brake is automatically locked.
The accelerator pedal on the right side of the driver is connected to the controller
via wires to control engine speed and thus control the speed of the loader The
inching pedal on the left side of the driver is connected to the front axle brake
drum via the brake hose to control the speed of the loader.
