Steering wheel
Instrument panel
NOTE
It is important that the operator adjusts the seating position and gets familiar with the controls before starting to
work.
NOTE
The root mean square value of the vibration acceleration of the machine acting on the arm is less than 2.5m/s2.
The root mean square value of the vibration acceleration of the machine acting on the whole body is less than 0.5m/s2.
Switch
Ignition switch
Horn control switch
Headlight switch
Warning light switch
Parking brake switch
Turning signal switch
Far and near light switch
Wide light switch
Page 11/72
W11E | Operation manual
The operation of the steering wheel is the same as usual, that is, when the
steering wheel is rotated to the right, the loader turns to the right, and when the
steering wheel rotates to the left, the loader turns to the left.
Design control panel combined with the best driving comfort and efficiency.
Waterproof ignition switch for loader, including anti-restart function.
Mounted on the underside of the instrument panel.
Mounted on the underside of the instrument panel.
Mounted on the underside of the instrument panel.
Mounted on the underside of the instrument panel.
Mounted on the left handle of the instrument panel.
Mounted on the left handle of the instrument panel.
Mounted on the left handle of the instrument panel.
