Audio In RCA Connector (J4)

Part Description
Two channel right angle RCA jack
Two channel RCA interconnect cable Monster Cable

Audio Out RCA Connector (J5)

Part Description
Six channel right angle RCA jack
Two channel RCA interconnect cable Monster Cable

Headphone Out Jack (J6)

Part Description
3.5mm stereo jack ( )
J6

Power Jack (J7)

The power connector (
the EZ-KIT Lite board.
Part Description
2.5 mm Power Jack ( )
J7
Mating Power Supply (shipped with EZ-KIT Lite)
7.5V Power Supply
ADSP-21262 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Hardware Reference
Manufacturer
SWITCHCRAFT
Mating Cable
Manufacturer
SWITCHCRAFT
Mating Cable
Manufacturer
Shogyo
) provides all of the power necessary to operate
J7
Manufacturer
SWITCHCRAFT
Digi-Key
GlobTek
Part Number
PJRAS1X2S02
BI100-1M
Part Number
PJRAS2X2S01
BI100-1M
Part Number
SJ-0359AM-5
Part Number
RAPC712
SC1152-ND
TR9CC2000LCP-Y
3-17
