Common Hardware Breakpoint Attributes

Each of the three tabs in the Hardware Breakpoints dialog box has com-
mon attributes. The common attributes are described in
Table 2-8. Common Hardware Breakpoint Attributes
Attribute Description
Enable Enables each individual breakpoint.
Start Address Specify inclusive start and end addresses. Each pair of addresses sets up an
End Address address range for the particular breakpoint.
Exclusive Enables breaks outside of the specified (inclusive) address range.
Mode Data page and Other page only. This option specifies the modes that trig-
ger hardware breakpoints. The available choices are:
Disabled—disables the breakpoint
On Write—triggers the breakpoint on any write operation to the specified
address range
On Read—triggers the breakpoint on any read operation from the speci-
fied address range
Any Access—triggers the breakpoint on any read or write access to the
specified address range.
ADSP-21262 EZ-KIT Lite Evaluation System Manual
Using EZ-KIT Lite
Table 2-8.
2-13
