• Digital Audio Interface
CS8416 SPDIF receiver
RCA phono jack input
• LEDs
12 LEDs: 1 power (green), 1 board reset (red), 1 USB reset
(red), 1 USB monitor (amber), and 8 general purpose
(amber)
• Push Buttons
5 push buttons: 1 reset, 2 connected to DAI,
2 connected to DSP
• Expansion Interface (Type A)
Parallel Port,
• Other Features
JTAG ICE 14-pin header
0-ohm resistors for DSP current measurement
SPI header
DAI header
The EZ-KIT Lite board has a total of 1 MB of parallel Flash memory and
512 Kbit of SPI Flash memory. The Flash memories can store user-spe-
cific boot code, allowing the board to run as a stand-alone unit. For more
information, see "Using External Memory" on page 2-2
and Clock Ratio Select Switch (SW10)" on page
512 KB of SRAM, which can be used at runtime.
The DAI of the DSP connects to the AD1835A audio codec and the
CS8416 SPDIF receiver. These devices allow you to create digital and ana-
log audio signal processing applications. See
page 2-3 and "Using Digital Audio" on page 2-5
ADSP-21262 EZ-KIT Lite Evaluation System Manual
pins
FLAG
s, DAI, SPI
FLAG
3-11. The board also has
"Using Analog Audio" on
for more information.
Preface
and "Boot Mode
xiii
