Supported bus profiles
Supported transmission rate
of the bus connection to the
PLC
Supported transmission rates
Ethernet
Max. number of connections
to TCP/IP
Max. number of connections
to MPI, PROFIBUS, PPI
Supported software
Table 4: Technical data
Pin assignment
Assignment MPI/PROFIBUS interface
Port Signal
1 -
2 GND
3 RxD / TxD-P
4 -
5 DGND
6 DVCC
ACCON-NetLink-PRO compact
MPI, DP, standard, Universal
(DP/FMS), user-defined with
automatic detection, PPI
9.6 Kbps to 12 Mbps with
automatic detection
10/100 Mbps with automatic
detection
16
32
ACCON-S7-EasyLog, ACCON-
AGLink, DELTA LOGIC S7/S5-
OPC-Server. With the driver for
SIMATIC ACCON-S7-NET the
following software can be used;
SIMATIC Manager from V5.3,
WinCC, WinCC flexible, ProTool,
STEP7-Micro/WIN, TIA Portal
Meaning
Not used
Ground/ voltage supply (looped-through)
Received/transmission data-P
Not used
Ground for bus termination (looped-
through)
5 VDC for bus termination (looped-
through)
