Observe Variables
This function can only be used when the NetLink is Online and the RFC-
1006 mode is used. The activation is described in chapter »8«.
Parameters for monitoring variables:
MPI Address
Number of Variables
No.
Address Area
Address Index*
Result Value
Display Format
Description
To show the desired values the buttons »1x fetch«, for a refresh once,
or »cyclic fetch«, for a permanent online request, are available.
With »Save Configuration« the created mask including all set variables
and their descriptions can be stored in the ACCON-NetLink-PRO
compact.
The refresh rate is set to 0.5 seconds. If several stations use this
function from the TCP/IP side, then there is always only one connection
resource reserved in the ACCON-NetLink-PRO compact. During the
additional data exchange via MPI/PROFIBUS the »Observe Variables«
function has the lowest priority. Thus the refresh rate in the web
interface is dependent from the parallel bus load.
ACCON-NetLink-PRO compact
With the help of the dropdown menu
an active MPI/PROFIBUS address
(S7-CPU) is selected.
For a better overview the number of
the desired variables can be selected
between 1 and 10.
Continuous numeration.
The following items are supported: AB,
AW, AD, EB, EW, ED, MB, MW, MD,
DBB, DBW, DBD, Counter and Timer.
Address of the bytes which want to be
shown. * Data modules in the
nomenclature »Data module offset«
e. g.: 108.10
The output value of a pressed button
can be seen here.
Possible display modes are decimal,
hexadecimal or binary
Free-selectable description (max. 32
characters)
