Min. Tsdr
Tset
Tqui
Gap
Retry
Please keep in mind that a wrong parametrized ACCON-NetLink-PRO
compact can interfere with the bus so that a regular operating is not
possible any more.
Due to this reason the autobaud function is very handy. Thus the
correct parameters are used, automatically. But the CPU must support
this function.
Wrong bus parameters can interfere with the bus!
ACCON-NetLink-PRO compact
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
Using MPI this value is always »20«. With
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
Using MPI this value is always »12«. With
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
Using MPI this value is always »0«. With
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
Using MPI this value is always »5«. With
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
Using MPI this value is always »2«. With
PROFIBUS the respective value has to be
taken from the parametrization of the bus
master (normally the CPU).
