Device name
MPI/PPI/PROFIBUS status:
Device is not online
Currently used
connections
These Parameters are only shown if a connection to a PLC is
established:
Own station address
Online Bus
parameters
List of active stations
List of passive
stations
ACCON-NetLink-PRO compact
The name which was stored in the ACCON-
NetLink-PRO compact is shown here.
If the ACCON-NetLink-PRO compact is not
connected to a PLC, these words will be
shown red.
The number of used bus connections is
shown here.
If the ACCON-NetLink-PRO compact is active
on the bus, you have to enter the bus
address here.
If the ACCON-NetLink-PRO compact is active
on the bus, the itemized bus parameter set
is shown here.
If the ACCON-NetLink-PRO compact is active
on the bus, the list of active stations is
output here. The own address is displayed in
red.
If the ACCON-NetLink-PRO compact is active
on the bus, the list of passive stations is
output here.
