DELTA LOGIC ACCON-NetLink-PRO User Manual page 42

Rack/Slot-Mode
or
Routing over RFC
ON/OFF
Fix destination address
for R/S mode
or
Station address of
routing gateway
User/Password Settings
User
New password
Retype new password Repeat password with a maximum of 8 digits
Entered changes can be undone with the button »Cancel«.
By clicking on »Submit« the entered values are checked. If there is a
wrong input a possible solution is shown.
If all is correct, all changes are shown again and with a click on »Store«
the values will be stored in the ACCON-NetLink-PRO compact.
To activate the new configuration, the ACCON-NetLink-PRO compact
will be restarted after saving the new parameters.
If desired the ACCON-NetLink-PRO compact can be activated remotely
via the configuration interface. To do this click on »System Reset«.
ACCON-NetLink-PRO compact
(»ON«) Rack/Slot-Mode is active
(»OFF«) Addressed-Mode is active.
If the Rack/Slot-Mode is activated, all
incoming RFC1006 queries are forwarded
to the parametrized bus address.
Here you can set a Username (Default:
ACCON-NetLink-PRO compact)
Password with a maximum of 8 digits
41
