General
3.2

Stone formations

1.) The stone formations 1 – 20 shown
below are suitable among others for
mechanical installation. Other stone
formations can also be laid by machines
as long as the stones are packed in the
correct formation ready for the
machine to lay them.
2.) The stone formations 16 – 20 are
suitable for mechanical installation by
the shifting adapter PA (4140.0003).
3.) The stone formations 21 – 25 are
suitable for mechanical installation by
special adapter.
Special adapters SA for installation units 21–24 or similar are available on request (indicate stone formation).
●
The device is only designed for the use specified in this documentation.
●
Every other use is not authorized and is forbidden!
●
All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration
of conformity, and additional local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
●
The equipment is suited to the intended operation, the functioning and the working condition of the
equipment is examined, and the load is suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
ATTENTION: The use of this device is only permitted in proximity to the ground.
Only stone elements with parallel and plane surface are allowed to be picked-up and handled.
Because the gripping good could fall down.
