LEDs
LEDs
System component
Device status and
management
Ports
Other
System component
Serial cable
RJ-45 to DB9 adapter
AC power cord
Weight and physical dimensions
Height
Width
4.37 cm
44.0 cm
1.72 inches
17.32 inches
Environmental requirements
Condition
*
Ambient temperature
Relative humidity
Altitude
Shock
Vibration
Airflow
Heat dissipation
(worst case)
Operating noise
MTBF (25°C, 60% CL, Telec)
*.
Worst case operational temperature is measured at sea level with at least 4 fan assemblies, with maximum power consumption optics modules (5W
QSFP28/2W SFP28) fully loaded.
62
Description
Two LED types indicate device status:
Power (power supply)
Status (diagnostics)
LEDs indicate port status (link/activity)
Description
1 (Mini-USB to RJ-45)
1 (RJ-45 port to female DB9 connector)
IEC 320-C14
Depth
Fully loaded weight
(no transceivers)
44.47 cm
8.99 kg
17.51 inches
19.82 lb
Operational
-5°C to 50°C (23°F to 122°F) (F2B)
-5°C to 45°C (23°F to 113°F) (B2F), temporarily to 55°C with 6 fan
assemblies
5% to 95% at 50°C (122°F)
0 to 3,000 m (9,843 ft) safety
-60 to 4,000 m (13,123 ft) operational
20 G, 11 ms, half-sine wave
1 G sine, 0.4 grms random, 5-500 Hz
134 cfm (estimated with 2 power supplies, 5 fan assemblies)
DC power supply 475 W
AC power supply 489 W
52.6 dBA (5 fan assemblies, 25°C, typical loading)
303,683 hours with DC power supply
324,414 hours with AC power supply
Non-operational
-40°C to 70°C (-40°F to 158°F)
5% to 95% at 70°C (158°F)
0 to 12,000 m (39,370 ft)
33 G, 11 ms, half-sine wave
2.4 G sine, 1.1 grms random, 5-500 Hz
N/A
N/A
N/A
N/A
ExtremeSwitching SLX 9140 Hardware Installation Guide
9036857-00 Rev AA
