DEFINITY
Communications System
DEFINITY High Speed Link
User´s Guide
SINGLE HSL
INSTALLATION
D8W Cord
The parts required for installing a single DEFINITY High Speed
Link are listed below and are shown in Figure 2-2:
The HSL
AC power converter
D8W telephone line cord
V.35 cable
RS-366/RS-232 cable (optional)
D A TA
i n k
d L
p e e
h S
H i g
I T Y
F I N
E R
P O W
D E
T
T E S
V.35
Cable
FIGURE 2-2
Installation Materials — Single HSL
Chapter 2: Installation
HSL
AC Power Converter
RS-366/RS-232
Cable
Page 2-3
