To install an objective:
1. In the CellReporterXpress Software, on the Home Page, click
2. In the Available Acquisition Devices list, click
details for the device where you want to install an objective.
3. Click the Objectives tab.
4. In the tile for the objective you want to install, click Component Exchange.
5. Click the Choose Objective dropdown and select the objective you want to install.
6. Click Open Maintenance Door.
7. Install the objective in the slot by gently turning it clockwise.
8. Close the maintenance door.
9. In the CellReporterXpress Software, click Close Maintenance Door.
10. Click Close.
CAUTION! Retain the objective case for future storage needs. When not installed in
the instrument, an objective should always be stored in its case.
5063666 B
Note: When installing the objective, take care to avoid changing the correction
collar setting.
Chapter 4: Finishing Setup of the ImageXpress Pico System
Show Device Options to expand the
Devices.
