Molecular Devices ImageXpress Pico Installation Manual page 35

To install a filter cube:
1. In the CellReporterXpress Software, on the Home Page, click
2. In the Available Acquisition Devices list, click
details for the device where you want to install a filter cube.
3. Click the Filters tab.
4. In the tile for the filter cube you want to install, click Component Exchange.
5. Click the Choose Filter dropdown and select the filter cube you want to install.
6. Click Open Maintenance Door.
7. If needed, slightly rotate the filter cube turret by hand to get direct access to the filter
cube slot.
8. Install the filter cube in the slot by gently pushing it into the slot.
9. Close the maintenance door.
10. In the CellReporterXpress Software, click Close Maintenance Door.
11. Click Close.
CAUTION! Retain the filter cube packaging for future storage needs. When not
installed in the instrument, a filter cube should always be stored in its original
packaging.
5063666 B
Tip: The filter cube should "snap" into place.
Chapter 4: Finishing Setup of the ImageXpress Pico System
Show Device Options to expand the
Devices.
35
