ImageXpress Pico Personal Imaging System Installation Guide
Standalone Configuration
To connect cables for a standalone configuration:
1. Do the following to connect the supplied Ethernet cable:
a. Connect one end of the Ethernet cable to the LAN1 port on the instrument.
b. Connect the other end of the Ethernet cable to an Ethernet port on the host
2. Do the following to connect the supplied power cord:
a. Connect the power cord to the power port on the instrument.
b. Connect the other end of the power cord to a grounded electrical wall outlet.
Network Configuration or Server Configuration
To connect cables for a network configuration or server configuration:
1. Do the following to connect the supplied Ethernet cable:
a. Connect one end of the Ethernet cable to the LAN2 port on the instrument.
b. Connect the other end of the Ethernet cable to a network port.
2. Do the following to connect the supplied power cord:
a. Connect the power cord to the power port on the instrument.
b. Connect the other end of the power cord to a grounded electrical wall outlet.
28
computer.
CAUTION! Do not simultaneously connect Ethernet cables to both the LAN1 port and
LAN2 port of the instrument. Doing so can degrade performance of the instrument or
cause unexpected behavior.
