Appendix A: Instrument Specifications

The instrument must be installed on a level and stable surface.
WARNING!
Devices, the protection provided by the equipment might be impaired.
WARNING!
relies on protective earth grounding for safe operation. Any interruption of the
protective earth ground conductor, inside or outside the instrument, or
disconnection of the protective earth ground terminal can result in personal
injury.
WARNING!
power switch on the front.
Item
Operating Environment
System Power
Fuse
Dimensions
Front Clearance (for maintenance
door)
Rear Clearance (space between
the rear of the instrument and
the wall for ventilation and cable
connections)
Top Clearance
Weight
Sample Formats (microplates)
Sample Formats (slides)
5063666 B
If the instrument is used in a manner not specified by Molecular
The ImageXpress Pico System is an Equipment Class 1 product that
Do not position the instrument so that it is difficult to operate the
Description
Indoor use only
100 VAC to 240 VAC, 50/60 Hz, 1.6 A nominal at 115 V, 200 W
maximum
Glass Tube 5x20 mm T6A250V
Width: 55.1 cm (21.7 in.)
Height: 45.3 cm (17.83 in.)
Depth: 42.5 cm (16.73 in.)
19.5 cm (7.68 in.)
20 cm to 30 cm (7.9 in. to 11.8 in.)
23.1 cm (9.1 in.)
38 kg (83.8 lb.)
ANSI/SLAS compliant
Number of Wells: 6, 12, 24, 48, 96, 384
Maximum Height, including lid: 22 mm (0.87 in.)
Standard microscope slides
25 mm x 75 mm (1 in. x 3 in.)
