Morita Veraview iX Operation Instructions Manual page 31

Specifications
Generator/X-ray Head Assembly
Model
Operating Tube Potential
Operating Tube Current
Reproducibility of Air Kerma
Maximum Output Power
Total Filtration
Beam Quality
Protective Shielding
Duty Cycle
Filament
Rectification
Cooling
Maximum Heat Unit of X-ray Head
Maximum continues input
Leakage Radiation
Source Skin Distance (SSD)
X-ray Field Size
Reference Axis
Weight of X-ray Head
Outer Dimension of X-ray Head
Max. Temperature of the Cone
Irradiation Time Range
0.01 to 2.0 sec. (series R'10 IEC60601-1-3: 2008 Annex B)
Accuracy
Minimum mAs
Operation 2018-10-22
V080
60/70 kV (accuracy : setting values ±10%)
7 mA fixed (accuracy : ±10%)
Coefficient of variation max. 0.05
490 W (70 kV, 7 mA, 0.1 sec.)
Min. 2.3 mmAl, 70 kV/HVL 3.1 mm.
(Fixed added filter; minimum 1.3 mmAl, X-ray tube filtration; 1.0 mmAl)
HVL minimum 1.5 mmAl at 70 kV
0.3 mm Pb or equivalent
1:29 (70 kV, 7 mA, for example 2 sec. exposure per 58 seconds cool-down period*)
* The maximum exposure time is 2 sec.
* The minimum interval is limited to 15 seconds to protect the hardware including
the X-ray tube.
Preheated
Direct Current
Oil cooling
62.8 kJ (1 HU=1.35 Joule, 1 J = 1 Ws)
4.9 W
Max. 0.25 mGy/h at 1 m
200 mm (Standard cone)
300 mm (Long cone) (Option)
Max. 60 mm diam. at the end plane of the cone
Runs axially with the cone
Approximately 3.5 kg
Approximately 280 × 220 × 92 mm (Standard cone)
Approximately 380 × 220 × 92 mm (Long cone)
Approximately +48°C at the ambient temperature of +40°C.
Setting value ±5% or ±20 ms
0.07 mAs
