Technical Specifications

Specifications

Model V080
Type EX-2
This unit is X-ray generator which includes X-ray source assembly and high-voltage generator.
Protection against Electric Shock
Protection against Ingress of Liquids
Operating Altitude
Pollution Degree
Overvoltage Category
Disinfection Methods
Mode of Operation
Type B Applied Part
Intended Use
Model V080 is a Dental X-ray unit using with an intra-oral X-ray image receptor. Model V080 is used for dental radiographic
examination and diagnosis of teeth, jaw and oral structure by exposing an X-ray image receptor to ionizing radiation.
To obtain diagnostic images, an appropriate imaging receptor shall be used with this device.
- CCD/CMOS type receptor: Detector line pair resolution 5 lp/mm or more, low contrast resolution diameter 1.0 mm or more.
- Imaging Plate type receptor: Scan resolution 5 lp/mm or more, low contrast resolution diameter 1.0 mm or more.
- Film: ISO speed of D or higher. E or F recommended.
For the European market, the receptor shall bear the CE marking.
X-ray Tube
Manufacturer / Model
Focal Spot
Target Angle
Target Material
Inherent Filtration
Nominal Anode Input Power
Maximum Anode Heat Content
Nominal Tube Voltage
Circuit (Center-Grounded)
Maximum Filament Current
Filament Voltage
Filament Frequency Limits
28
Class I, Type B
IPX 0
3,000 m (max.)
2
II
By wiping with Ethanol for Disinfection (Ethanol 70 vol% to 80 vol%).
Non-continuous operation
Head rest (no conductive connection to patients)
Toshiba or Canon Electron Tubes & Devices / D-0711SB
0.7 (IEC 60336)
16 degrees
Tungsten
At least 1.0 mmAl
940 W (1 sec.)
7 kJ (10 kHU)
70 kV
Constant Potential (DC)
3.0 A
3.0 V – 3.7 V (At max. Filament Current 3.0 A)
0 kHz – 20 kHz
[Specifications may be changed without notice due to improvements.]
