ArcLamps

Overview

Both the candle and globe shape provide a low-voltage LED lighting solution for chandeliers,
sconces, wall lights, proscenium lights, and more.
full load power consumption (4.4 W)
•
available in Fade to Warm (FTW) version with color temperature red-shift as it dims
•
available in CCT 2700 K (standard and FTW) or 3000 K (standard only) versions
•
low voltage (24 VDC) operation, powered and controlled from an ArcLamp Driver
•
dimmable from 0 to 100%
•
silent operation
•
ArcLamp LED lamps install directly to fixtures compatible with standard medium screw style (E26
or E27) and candelabra style (E12 or E14) bases.
A
C
A Globe Style
B Candle Style
E26 or E27 standard medium screw
C
style base
6
B A
D E
D E12 or E14 candelabra style base
E B15 bayonet style base
F B22 bayonet style base
B
F
