Control Specifications

Note:
channels.
All output channels have onboard overload protection. See
Operation on
ArcLamp System products can be controlled using wired DMX connections to the ArcLamp driver
or controlled using wireless ArcMesh protocol. The following graphic shows a basic hybrid
ArcLamp system installation with a wireless ArcLamp driver, ArcLamps, transmitter, and a wired
DMX console for the main control source.
ArcLamp systems are compliant with DMX 512-A (ANSI E1.11-2008 (R2013)).
DMX loss behavior is hold last look.
console
ArcLamp systems with an RDM driver can be controlled over wired DMX from a lighting console
or ETC Concert software. Concert is available for free download at etcconnect.com/Concert.
10
Each ArcLamp driver provides up to four individually addressable output
page 30.
wired DMX
wiring between
luminaire and
power supply
ArcMesh
wireless DMX
ArcLamp Driver
with wireless ArcMesh
Final Installation and
ArcLamps
in existing
fixture
TX1 Transmitter
ArcLamp System Installation Manual
