Power Input Wiring

This section provides power input wiring termination for standard wall-mount ArcLamp Driver
models. See Emergency Driver Power Input Wiring on page 46
normal sense and emergency power input wiring.
ArcLamp 150 Driver
ArcLamp Driver 150
Power Input Detail
Note:
and should follow standard wiring installation practices.
1. Make sure power is off at the main circuit breaker.
2. See Wire and Terminal Specifications on page 16
and terminal torque ratings. Prepare the wires accordingly.
3. Loosen the three screw terminals for NEUTRAL (N), GROUND
4. Insert the ground wire (typically green) into the GROUND
screw.
5. Insert the neutral wire (typically white) into the NEUTRAL (N) terminal and tighten the
screw.
6. Connect the hot wire (typically black) into the HOT (L) terminal and tighten the screw.
7. Tug gently on the wires to ensure they are secure.
Wall-Mount Driver Installation
Power wiring should only be installed and terminated by a qualified electrician
Factory Wire Colors
Model Color
North America
green/yellow
and Europe
North America black
North America white
Europe brown
Europe blue
for specification of wire, strip length,
for instructions to terminate
Type
ground/earth
line/hot
neutral
live
neutral
, and LINE (L) connections.
terminal and tighten the
