Maximum System Limits

Models are available to meet your installation requirements:
ArcLamp 150 Systems
Standard Wall-Mount
ARCLMD150CV24 with ArcMesh
ARCLRDMD150CV24 with RDM
Emergency Wall-Mount
ARCLMDE150CV24 with ArcMesh
ARCLRDMDE150CV24 with RDM
ArcLamp 350 Systems
Standard Wall-Mount
ARCLMD350CV24 with ArcMesh
ARCLRDMD50CV24 with RDM
Standard Rack-Mount
ARCLMDR350 with ArcMesh
ARCLRDMR350 with RDM
Emergency Wall-Mount
ARCLMDE350CV24 with ArcMesh
ARCLRDMDE350CV24 with RDM
Emergency Rack-Mount
ARCLMDRE350 with ArcMesh
ARCLRDMRE350 with RDM
ArcLamp 700 Systems
Standard Wall-Mount
ARCLMD700CV24 with ArcMesh
ARCLRDMD700CV24 with RDM
Standard Rack-Mount
ARCLMDR700 with ArcMesh
ARCLRDMR700 with RDM
Emergency Wall-Mount
ARCLMDE700CV24 with ArcMesh
ARCLRDMDE700CV24 with RDM
Emergency Rack-Mount
ARCLMDRE700 with ArcMesh
ARCLRDMRE700 with RDM
Note:
150 (standard or emergency model) for a total of 25 ArcLamps.
Note:
channels.
All output channels have onboard overload protection. See
Operation on
System Overview
It is possible to add a seventh ArcLamp to one channel of an ArcLamp Driver
Each ArcLamp Driver provides up to four individually addressable output
page 30.
Features
Supports 25 total 4.4 W ArcLamps, 6 per
channel
Max. current per channel: 1.5 A
Max. power per channel: 36 W
Features
Supports 60 total 4.4 W ArcLamps, 15 per
channel
Max. current per channel: 3 A
Max. power per channel: 72 W
Features
Supports 120 total 4.4 W ArcLamps, 30 per
channel
Max. current per channel: 6.1 A
Max. power per channel: 146 W
Final Installation and
