8.1.2 Electronics EG.708
Face plates
Short version
(for electronics EG. 707 and EG.708)
Part number G.704/150/02
Dimensions 170×20×141 mm
Material Plastic anti-static, PA 6
Colour black
Mounting · 2 cylinder screws Torx M4×12 mm
· 2 stretching thread inserts M4×10 mm
for wood and soft plastics
Miscellaneous · Hole depth at least 15 mm
· Ø 5.5 mm for thread inserts
Other accessories
Batteries
Part number K023
Dimensions 31×26×14 mm
Material Polyamide 66
Cable periphery 1×10-pin
RS-485 cable 1×7-pin
Cable length 120 mm
Area of use Electronics layout V1.4, V1.5
Comment The adapter PCB is clipped onto a PCB carrier with double-sided adhesive tape.
Long version
(for electronics EG. 707 and EG.708)
G.704/210/02
230×20×141 mm
Plastic anti-static, PA 6
black
· 2 cylinder screws Torx M4×12 mm
· 2 stretching thread inserts M4×10 mm
for wood and soft plastics
· Hole depth at least 15 mm
· Ø 5.5 mm for thread inserts
8 Accessories and individual parts
