KESO KEK i-handle S
Documentation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Ausgabedatum:
18.02.2011
Version:
018
3
4
4
6
11
12
14
20
21
23
24
25
28
29
32
32
32
ASSA ABLOY,
the global leader in
door opening solutions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KESO KEK i-handle S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Assa Abloy KESO KEK i-handle S

Summary of Contents for Assa Abloy KESO KEK i-handle S

  • Page 1: Table Of Contents

    KESO KEK i-handle S Documentation Important Notes Introduction Product description Requirements Article No. Definition Overview of fittings Technical data Operations Warning and Status Messages Emergency power / emergency opening Programming Settings Programming Home Version Installation Maintenance information Troubleshooting Product services...

  • Page 3: Important Notes

    Important notes on this documentation This documentation is part of the KESO KEK i-handle S product. It contains important notices on commissioning and handling. For this reason, you should familiarise yourself with the content and, in particular, observe the notes on safe installation, handling and operations. Make sure that this is complied with when passing on this product to third parties.

  • Page 4: Introduction

    Short description/functional description The KESO KEK i-handle S is a mechatronic door fitting with an integrated reader for interior use. The KESO i-handle S is independent of lock and cylinder and can thus be fitted to any popular door type.
  • Page 5 KESO KEK i-handle S System benefits with KESO KEK i-handle S • Fast and easy assembly • Easy retrofitting as independent of lock • Convenient operations • Can be combined with mechanical and mechatronic cylinders • Variable door width, spindle set can be replaced on site with very little effort •...

  • Page 6: Requirements

    Battery requirements The KESO KEK i-handle S is fully battery-operated. Note the signals in case of low battery power. In cold weather, or if fitted in cold rooms, please check the battery power several times per year.
  • Page 7 38 mm to 110 mm Important facts: The KESO KEK i-handle S is modular. The distance between the internal and external shield is defined by the spindle set. The spindle set can be replaced at any time. See item 5...
  • Page 8 KESO KEK i-handle S Mortise lock requirements The KESO KEK i-handle S can be used with most, commercially available door and mortise locks. Use only mortise locks by established lock manufacturers to guarantee standardised drilling patterns for KESO KEK i-handle S.
  • Page 9 140mm. Locking cylinder requirements The KESO KEK i-handle S is designed for use with Euro profile cylinders, Euro-Swiss cylinders and Swiss round cylinders. The KESO KEK i-handle S can also be used without a locking cylinder.
  • Page 10 KESO KEK i-handle S Fitting tool requirements • Assembly instructions included in packaging • Drilling template included in packaging • Drill • Drill tips 16mm and 25mm • Various slotted and Phillips screwdrivers • Multimetre to check the battery •...

  • Page 11: Article No. Definition

    KESO KEK i-handle S Article No. Definition KESO KEK i-handle S EG.711 _ _ _ Designs Sena, Inox Vector, Inox Xara, Inox Zafira, Inox EU Profile Euroswiss CH Profile Blind (internal, external) Surface Inox Hole spacing distance blind Hole spacing distance 72mm...

  • Page 12: Overview Of Fittings

    KESO KEK i-handle S Overview of fittings Please check scope of delivery before your start fitting. (lock and cylinder not included in scope of delivery) 7.10 Item Description Article SM Number Handle set hole component Model Sena G.380/SI Handle set hole component Model Vector G.308/VI...
  • Page 13 KESO KEK i-handle S 6.1.1 Dimensions ab 110 Depending on handle type Depending on handle type ab 110 KESO AG Subject to change without notice Page 13 from 34 pages...

  • Page 14: Technical Data

    KESO KEK i-handle S Technical data KESO KEK i-handle S Article No.: EG.711/… Application type: Stand alone Material shield/handle: Stainless steel Surface shield/handle: Satin Inox (others on request) Arbour: 8 mm Material reader module: Polycarbonate RAL 9005 Electronics: Electronics on interior of fitting, reader module in...
  • Page 15 KESO KEK i-handle S 7.1.1 Home Version Programming: With programming/deteting key/cards User keys: Up to 256 per KESO KEK i-handle S Programming keys: Up to 32 per KESO KEK i-handle S Deletion keys: unrestricted 7.1.2 PC Version (until end of 2010)
  • Page 16 KESO KEK i-handle S Handle set type SENA Article No.: G.380/SI Incl. mounting set (without shield) Hole component: 2 pcs. for 8mm arbour Dimensions: 130 x 60mm Material: Inox 7.2.1 Dimensions Handle set type VECTOR Article No.: G0.380/VI Incl. mounting set (without shield) Hole component: 2 pcs.
  • Page 17 KESO KEK i-handle S Handle set type XARA Article No.: G.380/XI Incl. mounting set (without shield) Hole component: 2 pcs. for 8mm arbour Dimensions: 130 x 56mm Material: Inox 7.4.1 Dimensions Handle set type ZAFIRA Article No.: G.380/ZI Incl. mounting set (without shield) Hole component: 2 pcs.
  • Page 18 KESO KEK i-handle S Spindle set and screws Spindle with stopper ring: 8 mm arbour Screws: 2 pcs. M5 round headed screws 1 pc. M5 countersunk screw Article No.: G.381/38/80 Door leaf thickness: 38-43 mm Article No.: G.381/44/80 Door leaf thickness: 44-49 mm Article No.:...
  • Page 19 KESO KEK i-handle S Reader module with connecting cable Article No.: K.027/01 Material: Polycarbonate RAL 9005 Dimensions: approx. 160 mm length approx. 5 mm diameter Battery Article No.: V.000/21/20 Set: 3 pc. Alkali manganese cells Type: LR03 (AAA) 1.5 V...

  • Page 20: Operations

    KESO KEK i-handle S 7.9.2 Dimensions Internal shield External shield 7.10 Basic module with electronics Article No. Home Version: EK.028.OHB.2 Article No. PC Version: EK.028.OPB.2 Article No. PC - Time Version: EK.028.PTB.2 Note: Depending on system Operations The sensor element in the reader is located above the external handle. A contactless reader is integrated into the security fitting.

  • Page 21: Warning And Status Messages

    KESO KEK i-handle S Warning and Status Messages Warning and status messages can be set or changed at any time with the KESO Management Software (see Item 4). The messages are set as follows as a factory default: Function Default...
  • Page 22 KESO KEK i-handle S 9.5.1 Prewarning threshold If the battery capacity drops below the prewarning threshold, an audible warning signal is emitted when a KEK medium is presented (as a factory default) and the green/red LEDs flash alternately. The prewarning threshold has no influence on access privileges.

  • Page 23: Emergency Power / Emergency Opening

    KESO KEK i-handle S Emergency power / emergency opening 10.1 Electronic Emergency power will only work in connection with the KESO KEK Programmer PPG V2 and the KAPI Bus interface at the reader module in the external shield. Important note: You must insert/place an authorized KESO medium in/on the KESO KEK Programmer PPG V2.

  • Page 24: Programming

    KESO KEK i-handle S Programming The KESO Management Software (see also 4) is the basis for programming and management in the PC Version or PC Time Version IMPORTANT: Always perform programming and deletion with the door open to avoid the door accidentally closing.

  • Page 25: Settings

    Please note that various settings can only be made with the PC Time Version. 12.1 KESO Management Software Settings You can make settings for the KESO KEK i-handle S with the KESO Management Software. Setting option Comment Handle operation time...
  • Page 26 KESO KEK i-handle S 12.2 Office Function You can use the Office function to override the always open time slot. Individual media (keys, tags, cards) can additionally be authorised to execute the Office function. 12.2.1 Office/Load Function The Office/Load function sets up the always open function not to start automatically in the assigned time slot.
  • Page 27 KESO KEK i-handle S 12.2.3 Office key function The Office key can set and reset the always open function within an authorised (access) time slot. Example 1 If a user of the office function is permitted for access, this user will always have the opportunity,...

  • Page 28: Programming Home Version

    KESO KEK i-handle S Programming Home Version As a user of a KESO HOME system you are responsible for managing your own keys. If you lose a master key belonging to a KESO HOME Version, the whole system has to be reprogrammed.

  • Page 29: Installation

    KESO KEK i-handle S Installation 14.1 Engineering drawing 14.2 Drilling template Drawing No. 800.377 IMPORTANT: Figure not 1:1 scale KESO AG Subject to change without notice Page 29 from 34 pages...
  • Page 30 KESO KEK i-handle S 14.3 Components 14.4 Changing the handle side Push 14.5 Changing the spindle set Remove spindle set Install spindle set KESO AG Subject to change without notice Page 30 from 34 pages...
  • Page 31 KESO KEK i-handle S 14.6 Installation When fitting the handle, it is important to make sure that the outside handle is not pressed too firmly against the plate. 14.7 Remove the central stud bolt Use a torx screwdriver (TX10) to remove the central stud bolt...

  • Page 32: Maintenance Information

    KESO KEK i-handle S Maintenance information 15.1 Mechanical parts The mechanical parts are maintenance-free to a great extent. Check that screws are tight at regular intervals. IMPORTANT: Opening the coupling mechanism (below the protective foil on the inside) voids your KESO AG warranty.
  • Page 34 +41 21 811 29 29 Telefax +49 4181 924-100 Telefax +41 21 811 29 00 E-Mail info@assa-keso.de E-Mail keso.sa@keso.com Internet www.assa-keso.de Internet www.keso.com ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safty and convenience.
