Page 3: Installation Diagrams
Installation Diagrams LBM WIRING Fail Safe* White Common Screws are loosened, but not removed Orange Normally Open Green Normally Closed Screws are moved to the Fail Safe position as shown Screws are tightened White *Fire rating only applies to Fail Orange Secure units. -
Page 4: Cutout Templates
Cutout Templates 8000/8300 with 801 Faceplate Inches [mm] 1-1/4” X 4-7/8” Square Corner Faceplate ANSI Metal Jamb Installations 1-1/4" [32] 4-7/8" [124] 4-1/8" [105] 3-3/8" [86] 1/8" [3] 3/16" [4.8] NOTE: The 8000/8300 electric strike with 801faceplate will fit right into most standard ANSI A115.2, 1”...
