Specifications - GRAPHTEC midi LOGGER GLT400 Quick Manual Start

<Standard specifications>
Items
Number of analog
channels
External input and output
PC I/F
Built-in memory device
Sampling interval
Back-up functions
Clock accuracy (ambient
temperature 23°C)
Operating environment
Power supply
Power consumption
External dimensions
(approx.)
Main unit with terminal
Weight (approx.)
Main unit with terminal
Vibration proof

Specifications

Up to 200 channels can be used with maximum 10 units
(In REMOTE mode, up to 180 channels can be used with maximum 9 units)
Trigger input or External sample pulse: 1ch
Logic input: 4ch or Pulse input: 4ch (in STAND-ALONE mode only)
Alarm output: 4ch (only 1ch in REMOTE mode)
Ethernet (10BASE-T/100BASE-TX), USB 2.0 (compatible with high
speed)
Internal memory (MEM): approx. 4GB
SD CARD slot: 1 slot (compatible with SDHC, maximum 32GByte
memory available)
* Possible to save maximum 2GB for one file
10ms/1ch MAX (GBD/CSV format)
10, 20, 50, 100, 125, 200, 250, 500 msec, 1, 2, 5, 10, 20, 30 sec
1, 2, 5, 10, 20, 30 min, 1 hour, External
* Allowable setting varies with the input setting and the number of
measuring channels.
* "External" can be selected in STAND-ALONE only.
Setup parameters: EEPROM/Clock: Lithium secondary battery
±0.002% (approx. 50 seconds per month)
-20 to 60°C, 5 to 85%RH (Supplied AC adapter: 0 to 45°C, When USB PD
is used as the power supply, it depends on the power supply specifications.)
AC adapter: 100 to 240VAC, 50 to 60 Hz
DC input: 8.5 to 24V DC (26.4V max.)
USB power supply: Compatible with USB PD, external USB PD
compatible battery
AC power consumption * When using the supplied AC adapter.
No Power supply
1 AC100V
2 AC240V
DC current consumption
No DC voltage
1 +24V
2
+12V
3 +8.5V
Standard terminal: 187.5 x 183 x 65.5 mm
High-voltage high-precision terminal: 187.5 x 183 x 73.4 mm
Screwless terminal: 187.5 x 183 x 65.5 mm
With standard terminal: 1090g/With high-voltage high-precision terminal:
1120g/With screwless terminal: 1020 g
Equivalent to Automobile Parts Type 1 Category A Classification
13
Description
Power consumption
24VA
35VA
Current consumption
0.36A
0.70A
1.00A
