11. Mode switch
The Mode switch is used to switch to one of three modes: STAND-ALONE, USB
DRIVE, REMOTE.
Switch the Mode switch when the power of the GLT400 is Off.
The mode is not switched even if the Mode switch is switched when the power of the
• GLT400 is On. You need to perform the power cycle.
STAND-ALONE
When using the GLT400 as a single recorder, set to "STAND-ALONE". You can control
•
capturing with the GLT400 alone or with PC software.
USB DRIVE
Set to "USB DRIVE" when accessing the internal memory and SD CARD from the PC
•
as external drive.
REMOTE
Set to "REMOTE" when connecting the GLT400 as a Remote Unit of the GL840.
To connect as a Remote Unit, refer to the GL840 User's Manual.
12. Protective cover
13. SD CARD slot
14. Wireless unit mounting terminal
The wireless unit terminal is used to connect the option B-568. (It cannot be used
with SD CARD at the same time.)
15. M4-L5 nut (Use for cable clamp, etc.)
16. Power jack for humidity sensor (B-530 option)
17. USB PD connector (for power supply)
18. GND terminal
19. AC adapter jack
20. External input/output terminals
This is used to connect B-513 (option).
(Input: LOGIC/PULSE, EXT TRIG/SAMPLE Output: ALARM)
21. USB interface terminal
22. LAN interface terminal
LAN LED
Mode Switch state
STAND-ALONE / REMOTE
USB DRIVE
23. Expansion terminal base connection terminal
24. Connector cover
* For details on the operation of other keys, refer to the User's Manual.
Lighting state
Not lit LAN communication is not performing
Lit in green
LAN communication is performing.
Flashes in green Automatic IP Address Acquisition (DHCP) is being
performed.
Always not lit Not used
