GRAPHTEC midi LOGGER GLT400 Quick Manual Start page 9

* Confirm that the writing is
not locked.
• To remove the SD CARD, confirm that the "SD ACCESS" LED is not lit and then remove it.
• When replacing the SD CARD during capturing, follow the replacement procedure.
To connect the GLT400 to the PC, use a cable with A-type and B-type connectors.
In USB DRIVE mode, the GLT400 operates as an external drive for internal memory and SD
CARD.
If using our application with a USB cable, you need to install the USB driver on the PC. For
the installation, refer to the "USB Driver Installation Manual".
Mounting SD CARD
<How to mount>
1
. Remove the SD CARD
protective cover.
2
. Insert the SD CARD until it
clicks and is firmly placed
inside the slot.
Connect the USB cable
A-type connector
<How to remove>
1
. The SD CARD is released by
pushing gently on the SD
CARD. Then, pull to remove
the SD CARD.
B-type connector
8
