ASSEMBLY

• To hire an authorized service technician to
assemble the weight bench, call 1-800-445-2480.
• Because of its weight and size, assemble the
weight bench in the location where it will be used.
Make sure that there is enough clearance to walk
around it.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is finished.
• Left parts are marked "L" or "Left" and right parts
are marked "R" or "Right."
• For help identifying small parts, see page 8.
1. Go to my.proform.com on your computer and
register your product.
• documents your ownership
• activates your warranty
• ensures priority customer support if assistance
is ever needed
Note: If you do not have internet access, call
Customer Care (see the front cover of this
manual) and register your product.
2. Attach the Front Stabilizer (2) to the Bench
Frame (1) with two M10 x 65mm Carriage Bolts
(26) and two M10 Locknuts (15); do not tighten
the Locknuts yet.
• Assembly requires two persons.
• In addition to the included tool(s), assembly
requires the following tool(s):
one adjustable wrench
one rubber mallet
one Phillips screwdriver
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
1
2
15
2
26
10
1
