15. Identify the Left Weight Rest (42), insert it into
one of the holes in the left Upright (36), and
rotate it so that it is wrapped around the Upright.
Next, identify the Left Spotter (43), and attach it
to the left Upright (36) in the same way.
Attach the Right Weight Rest (40) and the
Right Spotter (41) to the right Upright (36) in
the same way.
Make sure that both Weight Rests (40, 42)
are at the same height and that both Spotters
(41, 43) are at the same height.
16. Insert a Band Anchor (44) through one of the
holes in the left Base (47). Then, slide a Large
Washer (55) onto the Band Anchor, and insert a
Cotter Pin (49) through the Band Anchor.
Attach the other Band Anchor (not shown) to
the right Base (47) in the same way.
17. Make sure that all parts are properly tightened before you use the weight bench. The use of all
remaining parts will be explained in ADJUSTMENT on page 17.
15
40
36
41
16
47
16
36
42
43
49
55
47
44
