Pro-Form Carbon Strength Olympic System User Manual page 18

STORING YOUR WEIGHT PLATES
To store your weight plates (not included), slide them
onto the Weight Tubes (46).
WARNING:
than 150 lbs. (68 kg) of weight on each
Weight Tube (46).
ADJUSTING THE BACKREST
To adjust the angle of the Backrest (8), firmly hold
the Backrest with one hand. With your other
hand, pull the indicated Knob (9), raise or lower the
Backrest, and then release the Knob into one of the
adjustment holes in the Backrest Bracket (6).
WARNING:
Backrest (8) before you pull the Knob (9);
the Backrest can fall with great force.
ADJUSTING THE SEAT
To adjust the angle of the Seat (7), firmly hold the
Seat with one hand. With your other hand, pull the
indicated Knob (9), raise or lower the Seat, and then
release the Knob into one of the adjustment holes in
the Seat Bracket (33).
WARNING:
Seat (7) before you pull the Knob (9); the
Seat can fall with great force.
Do not place more
Always hold the
Always hold the
46
18
46
8
9
6
7
9
33
