Pro-Form Carbon Strength Olympic System User Manual page 11

3. Attach the Rear Stabilizer (3) to the Bench
Frame (1) with two M10 x 95mm Bolts (56), two
M10 Washers (22), and two M10 Locknuts (15).
See step 2. Tighten the M10 Locknuts (15).
4. Attach the Seat Bracket (33) to the Seat Frame
(4) with two M10 x 100mm Bolts (19), two M10
Washers (22), and two M10 Locknuts (15); do
not tighten the Locknuts yet.
Then, attach the Seat (7) to the Seat Frame (4)
with four M6 x 25mm Screws (20); start all four
Screws, and then tighten them.
5. Attach the Backrest Bracket (6) to the Backrest
Frame (5) with two M10 x 105mm Bolts (28), two
M10 Washers (22), and two M10 Locknuts (15);
do not tighten the Locknuts yet.
Then, attach the Backrest (8) to the Backrest
Frame (5) with two M6 x 25mm Screws (20), an
M6 x 70mm Screw (24), and an M6 Washer (25);
start all three Screws, and then tighten them.
3
15
4
7
22
15
22
20
5
8
15
22
25
24
11
1
22
15
3
4
19
33
20
19
5
22
20
20
28
6
56
22
11
