Technical Specifications
5.6 Mechanical Specifications
5.6
Mechanical Specifications
Weight
Ingress Protection
Enclosure
5.7
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Figure 5.1
30
3.75 kg (8.3 lbs)
IP40 for LO power supply, IP30 for HI power supply
Die Cast Aluminum
116.1
Overall Dimensions
164.5
RUGGEDCOM RST916C
Installation Manual, 04/2021, C79000-G8976-1490-03
