Technical Specifications

This section provides important technical specifications related to the device.
5.1

Power Supply Specifications

Note
When determining cable lengths, make sure the minimum input voltage for the
power supply is provided at the power source.
Hazardous Environments
Power
Supply Type
Minimum
LO 11.1 VDC
HI 100 VDC
100 VAC
a
Current consumption may vary based on configuration.
Non-Hazardous Environments
Power
Supply Type
Minimum
LO 10 VDC
HI 88 VDC
85 VAC
a
Current consumption may vary based on configuration.
RUGGEDCOM RST916C
Installation Manual, 04/2021, C79000-G8976-1490-03
Input Voltage
Maximum Nominal
55 VDC 12 VDC, 24
VDC, 48 VDC
270 VDC 125 VDC,
250 VDC
240 VAC 110 VAC,
220 VAC
Input Voltage
Maximum Nominal
60 VDC 12 VDC, 24
VDC, 48 VDC
300 VDC 125 VDC,
250 VDC
264 VAC 110 VAC,
220 VAC
Internal Isolation
Fuse Rating
5 A 1.5 kVDC
3.15 A 5 kVDC
3.15 A 5 kVDC
Internal Isolation
Fuse Rating
5 A 1.5 kVDC
3.15 A 5 kVDC
3.15 A 5 kVDC
5
Maximum
Power
a
Consumption
13.4 W
15.3 W
15.5 W
Maximum
Power
a
Consumption
13.4 W
15.3 W
15.5 W
