Operating Environment; Mechanical Specifications - Siemens SIMATIC NET RUGGEDCOM RS900 Equipment Manual

Connector
Mode
Type
MM MTRJ
MM SC
MM ST
MM LC
SM ST
SM LC
SM LC
SM LC
SM SC
SM SC
SM SC
a
Typical.
5.7

Operating Environment

The RUGGEDCOM RS900 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.8

Mechanical Specifications

Weight
Ingress Protection
Enclosure
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
Tx λ Cable
a
(nm) Type (μm) Minimum Maximum
50/125 -22.5
1300
62.5/125
50/125 -22.5
1300
62.5/125
50/125 -22.5
1300
62.5/125
1310 62.5/125
1310 9/125
1300 9/125
1310 9/125
1310 9/125
1300 9/125
1310 9/125
1310 9/125
a
b
Tx (dBm) Rx
Sensitivity
(dBm)
-14 -33.5
-19 -14 -33.5
-14 -33.9
-19 -14 -33.9
-14 -33.9
-19 -14 -33.9
-19 -14 -32
-15 -7 -34
-15 -8 -38
-5 0 -35
0 5 -37
-15 -8 -31
-5 0 -34
5 0 -37
-40 to 85 °C (-40 to 185 °F)
-40 to 85 °C (-40 to 185 °F)
5% to 95%
2000 m (6562 ft)
1.2 kg (2.7 lbs)
IP30
20 AWG Galvanized Steel
Technical Specifications
5.7 Operating Environment
Rx
Distance
Saturation
a
(km)
(dBm)
-14 2
-14 2
-14 2
-14 2
-14 2
-14 2
-14 2
-3 20
-3 20
-3 50
0 90
-7 20
-3 50
0 90
Power
Budget
(dB)
11
14.5
11.4
14.9
11.4
14.9
13
19
23
30
37
16
29
42
27
