External Sensor Page; Figure 23 External Sensor Page - Michell Instruments XTP601 User Manual

XTP601 User's Manual
2.7.7

External Sensor Page

This page sets up the type and range of the 4-20 mA external sensor signal that may
be connected to the XTP601 for viewing in the Main Page. The range is adjustable
between the MIN and MAX values but is not adjustable for
and 100%).
Setting
EXT.SENS PV
EXT.SENS MIN
EX.SENS MAX
UNIT
Michell Instruments
EXT.SENS PV
EXT.SENS MIN
EXT.SENS MAX
UNIT
Figure 23
Description/Operation
The process variable that is being measured by
the external sensor
Select to turn the feature off
None
represents a user-defined variable
Other
Depends on parameter and unit settings:
Dew point: -100°C, -148°F, 173.0 K
Temperature: -50°C, -58°F, 223.0 K
Pressure: 0.0 psia, 0.0 bara, 0.0 kpa
Other: 0% (non adjustable)
Depends on parameter and unit settings:
Dew point: 20°C, 68°F, 293.0 K
Temperature: 100°C, 212°F, 373.0 K
Pressure: 44.1 psia, 3.0 bara, 304.0 kpa
Other: 100% (non adjustable)
These are related to the type of sensor selected
If is selected, then the unit will be a % of
Other
the overall range
tempr
-50.0
100.0
ºC
External Sensor Page
Other
OPERATION
setting (fixed at 0%
Options
None, Dewpoint,
tempr, Pressure,
Other
minimum to
EXT.SENS MAX
EXT.SENS MIN
to maximum
ºC, ºF, K, psia, kPa,
bara, %
