Installation
3.3.2 Link Quality/Mode Indicators
RSSI (WLAN Client) / Link Quality (Bluetooth PANU)
LED
A
A B
A B
A B
These LEDs are also used when selecting an Easy Config mode and to indicate
update status in Recovery Mode.
See Easy Config, p. 12
®
Anybus Wireless Bridge II
Description
No connection
RSSI/Link Quality < 25 %
RSSI/Link Quality 25–50 %
RSSI/Link Quality 50–75 %
C
D RSSI/Link Quality > 75 %
C
and Recovery Mode LED Indications, p.
™
