Installation
3.4

MODE Button

The MODE button can be used to restart or reset the unit as well as for
selecting an Easy Config mode.
When the unit is powered on, press and hold MODE for >10 seconds and then
release it to reset to the factory default settings.
Recovery Mode
If the web interface cannot be accessed, the unit can be reset by starting in
Recovery Mode and reinstalling the firmware using Anybus Firmware Manager
II, which can be downloaded from www.anybus.com/support.
To enter Recovery Mode, press and hold RESET during startup.
Recovery Mode LED Indications
In Recovery Mode the Status LEDs will indicate firmware update status:
PWR
WLAN + BT
®
Anybus Wireless Bridge II
Firmware updates should normally be carried out through the web
interface. Recovery Mode should only be used if the unit is unresponsive
and the web interface cannot be accessed.
Green
Green, blinking
Alternating red/blue
™
Startup Guide
Firmware update in progress
Waiting for valid firmware
Firmware update in progress
