Safety
2.3

Intended Use

The intended use of this equipment is as a communication interface and
gateway. The equipment receives and transmits data on various physical levels
and connection types.
If this equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
2.4

Type Identification

The type name consists of a type prefix followed by two designators for
interface configuration and functionality.
Prefix
Interface configuration
Functionality
Example: AWB3AA = Anybus Wireless Bridge II with internal antenna, Ethernet
networking and digital input.
®
Anybus Wireless Bridge II
AWB3
A
B
A
B
™
Startup Guide
Anybus Wireless Bridge II
Internal antenna, Dual M12
External antenna, Dual M12, RP-SMA
Ethernet with digital input
Ethernet w/o digital input
