6 - Magnetic Stripe Card Data Sent from Device to Host (MSR Only | Keypad Entry Only)
Bit Position 7
Value Reserved Reserved Reserved Reserved Reserved Reserved Reserved Error
6.5

Card Encode Type (HID | TLV | GATT | SLIP)

This one-byte value indicates the type of encoding the device found on a swiped magnetic stripe card.
Table 6-3 defines the possible values. For details about how the device determines the card's encode
type, see Appendix C Identifying ISO/ABA and AAMVA Cards For Masking (MSR Only).
Format
HID
Streaming
TLV
GATT/SLIP
Table 6-3 - Card Encode Types
Value Encode Type
0 ISO/ABA
1 AAMVA
2 Reserved
3 Blank
4 Other
5 Undetermined
eDynamo| Secure Card Reader Authenticator | Programmer's Manual (COMMANDS)
6 5
Usage 0x38
N/A
Data Object 8261
Offset 6
ISO/ABA encode format. At least one track in ISO/ABA format, Track 3
not AAMVA format. See Appendix C Identifying ISO/ABA and
AAMVA Cards for ISO/ABA description.
AAMVA encode format. Track 3 is AAMVA format, Tracks 1 and 2 are
ISO/ABA if correctly decoded. See Appendix C Identifying ISO/ABA
and AAMVA Cards for AAMVA description.
Reserved.
The card is blank. All tracks decoded without error and without data.
The card has a non-standard encode format. For example, ISO/ABA track 1
format on track 2.
The card encode type could not be determined because no tracks could be
decoded. Combination of Error tracks and Blank Tracks, at least one Error
track.
Page 42 of 245 (D998200115-17)
4 3 2
Where to Find Value
Description
1 0
