- Page 1 USB MagneSafe V5 Swipe and Insert Reader TECHNICAL REFERENCE MANUAL PART NUMBER 99875388-9 JUNE 2012 REGISTERED TO ISO 9001:2008 1710 Apollo Court Seal Beach, CA 90740 Phone: (562) 546-6400 FAX: (562) 546-6301 Technical Support: (651) 415-6800 www.magtek.com...
- Page 2 Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of MagTek, Inc. MagTek is a registered trademark of MagTek, Inc.
- Page 3 This warranty shall be provided only for a period of one year from the date of the shipment of the product from MagTek (the “Warranty Period”). This warranty shall apply only to the “Buyer” (the original purchaser, unless that entity resells the product as authorized by MagTek, in which event this warranty shall apply only to the first repurchaser).
- Page 4 FCC WARNING STATEMENT This equipment has been tested and was found to comply with the limits for a Class B digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.
-
Page 5: Table Of Contents
TABLE OF CONTENTS SECTION 1. FEATURES AND SPECIFICATIONS ..............1 FEATURES ............................... 2 HARDWARE CONFIGURATION ......................3 ACCESSORIES ............................4 REFERENCE DOCUMENTS ........................4 SPECIFICATIONS ............................ 5 SECTION 2. INSTALLATION ....................7 USB CONNECTION ..........................7 WINDOWS PLUG AND PLAY SETUP ..................... 8 MOUNTING .............................. - Page 7 Figure 1-1. USB MagneSafe Swipe Reader – Full Size Figure 1-2. USB MagneSafe Swipe Reader – Mini Figure 1-3. USB MagneSafe Swipe Readers – P55 and P90...
- Page 8 Figure 1-4. USB MagneSafe Insert Reader without bezel Figure 1-5. USB MagneSafe P-Series Insert Reader with Extended bezel viii...
-
Page 9: Section 1. Features And Specifications
SECTION 1. FEATURES AND SPECIFICATIONS The USB (Universal Serial Bus) Readers are compact magnetic stripe card readers that conform to ISO standards. In addition to reading multiple tracks of data from a card, the Readers also include MagnePrint technology. The MagnePrint data will be included with the track data on each transaction. -
Page 10: Features
USB MagneSafe V5 Swipe and Insert Reader FEATURES Major features of the Readers are as follows: • Wired model and wireless model dongle powered through the USB – no external power supply required • Wireless model reader is powered by a rechargeable battery; recharging can be provided via a standard USB cable (for recharging only) •... -
Page 11: Hardware Configuration
Section 1. Features and Specifications HARDWARE CONFIGURATION The hardware configuration is as follows: Part Number Tracks Style Connector Cable Insert (IntelliStripe 65 style) 21063015 1, 2, 3 USB mini-B Optional No Bezel, Head Right Insert (IntelliStripe 65 style) 21063016 1, 2, 3 USB mini-B Optional International Bezel, Head Right... -
Page 12: Accessories
USB MSR Demo Program with Source Code (WEB) REFERENCE DOCUMENTS MagTek Communication Reference Manual for USB MagneSafe V5 Readers (99875475) Axelson, Jan. USB Complete, Everything You Need to Develop Custom USB Peripherals, 1999. Lakeview Research, 2209 Winnebago St., Madison WI 53704, 396pp., http://www.lvr.com. -
Page 13: Specifications
Section 1. Features and Specifications SPECIFICATIONS Table 1-2 lists the specifications for the USB MagneSafe Readers. Table 1-2. Specifications Reference Standards ISO 7810 and ISO 7811/ AAMVA* Power Input 5V from USB bus Recording Method Two-frequency coherent phase (F2F) Message Format ASCII Card Speed 4 to 60 ips (10.1 to 152.4 cm/s) - Page 14 USB MagneSafe V5 Swipe and Insert Reader Figure 1-2. Dimensions for Mini Reader Figure 1-3. Dimensions for Full Size Reader...
-
Page 15: Section 2. Installation
SECTION 2. INSTALLATION This section describes the cable connection, the Windows Plug and Play Setup, and the physical mounting of the unit. USB CONNECTION Connect the USB cable or dongle for the wireless model to a USB port on the host. The Reader, LED Indicator, and pin numbers for the 4-pin connector are shown in Figure 2-1. -
Page 16: Windows Plug And Play Setup
USB MagneSafe V5 Swipe and Insert Reader WINDOWS PLUG AND PLAY SETUP On hosts with the Windows operating system, the first time the reader is plugged into a specific USB port, Windows will pop up a dialog box, which will guide you through the process of installing a device driver for the reader. - Page 17 Section 2. Installation Figure 2-2. Mounting Hole Dimensions for Full Size Reader Figure 2-3. Mounting Hole Dimensions for Mini Reader Ensure the Reader is positioned on a flat, accessible surface with at least 4 inches clearance on either end for room to swipe a card. If fastening tape is to be used, clean the area that the Reader will be mounted on with isopropyl alcohol.
- Page 18 USB MagneSafe V5 Swipe and Insert Reader...
-
Page 19: Section 3. Operation
SECTION 3. OPERATION USER SWITCH Only the wireless reader model includes a user switch. This section only applies to the wireless model. The User Switch, or Power Switch, is located on the side of the reader. Pressing the User Switch when the reader is off will turn the reader on. The reader will stay on for a predetermined amount of time (the default is 120 seconds) or until the completion of a card read transaction. -
Page 20: Card Read
USB MagneSafe V5 Swipe and Insert Reader For the wireless reader, after a card swipe but prior to indicating the status of decoding the card data when data should be transmitted wirelessly, if the the reader is out of range the green LED will blink rapidly (~10 times a second) until the reader is back in range (when data is transmitted). - Page 21 Section 3. Operation Example 1 – Power Up followed by Authentication and good swipe: 1. Reader Powers Up (State = WaitActAuth:PU). This is typically right after the USB connection becomes available to the application. Application should send the Get Reader State Command to discover the current state of the reader.
-
Page 22: Charging The Wireless Reader Battery
USB MagneSafe V5 Swipe and Insert Reader command (State => WaitActAuth:TOAuth). Host doesn’t know because the reader can/does not send any message. 4. Host finally sends Activation Challenge Reply command (State remains WaitActAuth:TOAuth). Reader responds with RC=0x07 inferring the previous transition to WaitActAuth:TOAuth state. CHARGING THE WIRELESS READER BATTERY As mentioned above (LED Indicator), the wireless reader may indicate low battery at power up by showing red for two seconds then turn solid green. -
Page 23: Appendix A. Insert Reader Drawings
APPENDIX A. INSERT READER DRAWINGS This section contains the drawings showing the mounting dimensions for the Insert Reader models. The following drawings are included: 21063015 Mounting Specifications for 21063015 21063018 Mounting Specifications for 21063018 and 21063019 21063020 Mounting Specifications for 21063020 and 21063021 21063022 Specifications for 21063022 21063023... -
Page 24: Figure A-1. Mounting Specification For 21063015
USB MagneSafe V5 Swipe and Insert Reader ___________________________________________________________________________________________ Figure A-1. Mounting Specification for 21063015... -
Page 25: Figure A-2. Mounting Specification For 21063018 And 21063019
Appendix A. Drawings Figure A-2. Mounting Specification for 21063018 and 21063019... -
Page 26: Figure A-3. Mounting Specification For 21063020 And 21063021
USB MagneSafe V5 Swipe and Insert Reader Figure A-3. Mounting Specification for 21063020 and 21063021... -
Page 27: Figure A-4. Specification For 21063022
Appendix A. Drawings Figure A-4. Specification for 21063022... -
Page 28: Figure A-5. Specification For 21063023
USB MagneSafe V5 Swipe and Insert Reader Figure A-5. Specification for 21063023...
