Appendix B - Examples
B.1.1 Example: HID Device Card Swipe In Security Level 2 (HID Only, MSR Only)
This example shows the data received in a HID report for a device at Security Level 2 [see section 2.1
How to Use USB Connections (USB Only)].
The raw HID report is:
Byte Content
0 00 00 00 3C 25 1F 00 25 42 35 34 35 32 33 30 30 35 35 31 32
20 32 37 31 38 39 5E 48 4F 47 41 4E 2F 50 41 55 4C 20 20 20 20
40 20 20 5E 30 38 30 34 33 32 31 30 30 30 30 30 30 30 37 32 35
60 30 30 30 30 30 30 3F 00 00 00 00 00 00 00 00 00 00 00 00 00
80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
100 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 3B
120 35 34 35 32 33 30 30 35 35 31 32 32 37 31 38 39 3D 30 38 30
140 34 33 32 31 30 30 30 30 30 30 30 37 32 35 30 3F 00 00 00 00
160 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
180 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
200 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
220 00 00 00 00 00 00 00 00 00 00 00 3B 35 31 36 33 34 39 39 30
240 38 30 30 32 30 34 34 35 3D 30 30 30 30 30 30 30 30 30 30 30
260 30 3F 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
280 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
300 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
320 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
340 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
360 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
380 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
400 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
420 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
440 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
460 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
480 00 00 00 00 00 00 00 00 00 00 00 00 00 00 02 00 00 00 00 00
500 00 00 00 00 00 3C 25 1F 25 42 35 34 35 32 33 30 30 35 35 31
520 32 32 37 31 38 39 5E 48 4F 47 41 4E 2F 50 41 55 4C 20 20 20
540 20 20 20 5E 30 38 30 34 33 32 31 30 30 30 30 30 30 30 37 32
560 35 30 30 30 30 30 30 3F 00 00 00 00 00 00 00 00 00 00 00 00
580 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
600 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
620 3B 35 34 35 32 33 30 30 35 35 31 32 32 37 31 38 39 3D 30 38
640 30 34 33 32 31 30 30 30 30 30 30 30 37 32 35 30 3F 00 00 00
660 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
680 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
700 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
720 00 00 00 00 00 00 00 00 00 00 00 00 3B 35 31 36 33 34 39 39
740 30 38 30 30 32 30 34 34 35 3D 30 30 30 30 30 30 30 30 30 30
760 30 30 3F 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
780 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
800 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
820 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
840 00 00 00 00 00 00 00 00 00 00 00 00 3C 25 1F 36
