9 - Properties
9.16 Property 0x38 - HID SureSwipe Flag (SureSwipe Only, HID Only, MSR
Only)
0x38
Property ID:
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0x00
This property enables/disables SureSwipe emulation when in Security Level 2 with Property 0x10 -
Interface Type set to HID. This allows customers to receive a device without security enabled (Security
Level 2) and use it in a similar manner to a SureSwipe device (for example, for convenience during
software development). Later, when the customer is ready, they can switch the device to a higher
Security Level and take advantage of the robust security features offered by the device.
When this property is set to 0x00, the device functions as described in this document.
When this property is set to 0x01, the device returns card swipes and enumerates with the same VID/PID
as described in D99875191 Technical Reference Manual, USB HID SureSwipe & Swipe Reader. It
does not emulate the property settings as defined there.
This property is only effective in USB HID mode.
This property is stored in non-volatile memory, so it persists when the device is power cycled. When this
property is changed, the device must be reset (see Command 0x02 - Reset Device) or powered off for at
least 30 seconds, then powered on, before the changes will take effect.
Example Set Request (Hex)
Cmd Num
01
Example Set Response (Hex)
Result Code
00
Example Get Request (Hex)
Cmd Num
00
Example Get Response (Hex)
Result Code
00
eDynamo| Secure Card Reader Authenticator | Programmer's Manual (COMMANDS)
Data Len
02
Data Len
00
Data Len
01
Data Len
01
Page 149 of 245 (D998200115-17)
Property ID
38
Data
Property ID
38
Data
01
Data
01
