9 - Properties

9.12 Property 0x15 - MagnePrint Flags (MSR Only)

0x15
Property ID:
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0x00
The host uses this property to direct the device to either include or exclude MagnePrint data in Magnetic
Stripe Card Data Sent from Device to Host (MSR Only | Keypad Entry Only) when the device is in
Security Level 2. At higher security levels, the device always sends encrypted MagnePrint data.
Bit Position
S = 0: Device does not include MagnePrint Data
S = 1: Device includes MagnePrint Data
Setting S to 1 directs the device to send MagnePrint Status, MagnePrint Data Length (HID | GATT |
SLIP), MagnePrint Absolute Data Length (HID | TLV | GATT | SLIP), and Encrypted MagnePrint
Data with each swipe when it is in Security Level 2.
Setting S to 0 directs the device to zero-fill these values.
Some devices are configured to only allow the manufacturer to modify this property.
This property is stored in non-volatile memory, so it persists when the device is power cycled. When this
property is changed, the device must be reset (see Command 0x02 - Reset Device) or powered off for at
least 30 seconds, then powered on, before the changes will take effect.
eDynamo| Secure Card Reader Authenticator | Programmer's Manual (COMMANDS)
7 6 5
0 0 0
Page 145 of 245 (D998200115-17)
4 3 2
0 0 0
1 0
0 S
