Appendix B - Examples
The HID report can be broken down using the information in section 6 Magnetic Stripe Card Data Sent
from Device to Host, which is summarized as the Offset and Usage Name columns of Table 9-3. This
provides a structure for organizing the raw data in the Data column:
Table 9-3 - Interpreting HID Data
Offset Usage Name
0 Track 1 decode status
1 Track 2 decode status
2 Track 3 decode status
3 Track 1 encrypted data length
4 Track 2 encrypted data length
5 Track 3 encrypted data length
6 Card encode type (ISO/ABA)
7..118 Track 1 encrypted data
119..230 Track 2 encrypted data
231..342 Track 3 encrypted data
343 Card status
344..347 MagnePrint status
348 MagnePrint data length
eDynamo| Secure Card Reader Authenticator | Programmer's Manual (COMMANDS)
00
00
00
3C (60 bytes, see Track 1 encrypted data below)
25 (37 bytes, see Track 2 encrypted data below)
1F (31 bytes, see Track 3 encrypted data below)
00
60 bytes, not encrypted, device is in security level 2:
25 42 35 34 35 32 33 30 30 35 35 31 32 32 37 31 38 39
5E 48 4F 47 41 4E 2F 50 41 55 4C 20 20 20 20 20 20 5E
30 38 30 34 33 32 31 30 30 30 30 30 30 30 37 32 35 30
30 30 30 30 30 3F 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00
37 bytes, not encrypted, device is in security level 2:
3B 35 34 35 32 33 30 30 35 35 31 32 32 37 31 38 39 3D
30 38 30 34 33 32 31 30 30 30 30 30 30 30 37 32 35 30
3F 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00
31 bytes, not encrypted, device is in security level 2:
3B 35 31 36 33 34 39 39 30 38 30 30 32 30 34 34 35 3D
30 30 30 30 30 30 30 30 30 30 30 30 3F 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00
00 (not used, always zero)
00 00 00 00 (not available in Security Level 2)
00 (Security Level 2, no MagnePrint data)
Page 190 of 245 (D998200115-17)
