Code for integrated control unit PICO-troniX1

Construction type no.
Connection* Bayonet plug-type connection Hirschmann plug-type connection
Code no.
Integrated control unit
Code no.
Parameters
Time-dependent 1 - 16 min
lubrication 2 - 32 min
duration 2 - 32 s
Revolution- 1 - 16 rev.
dependent 10 - 160 rev.
lubr. duration 170 - 320 rev.
Special version
Code no.
* for 12 and 24 V DC
The integrated control unit PICO-troniX1 can be retrofit at devices without integrated control unit or
can be used as replacement for another integrated control unit.
Notice!
The integrated control unit is supplied without connect
Required connection plugs or connection cables have to be ordered separately (order numbers on
request).
