9.2.2 Changing and setting the parameters
The operational modes and setting ranges of the cycle duration and lubrication duration can be changed at any time using
the diagnosis software BEKA-DiSys
When the parameters are changed, the adhesive label in the inspection window of the protective housing has to be
exchanged accordingly.
The adhesive labels for the inspection window can be ordered as needed.
Time-dependent cycle duration
0,5 - 8 h
Time-dependent lubrication duration
I 1 - 16 min 10115218 10116324
II 2 - 32 min 10115227 10116325
III 2 - 32 s 10116326 10116327
Pulse-dependent lubrication duration
I 1 - 16 Takte 10115235 10116340
II 17 - 32 Takte 10115246 10116342
III 33 - 48 Takte 10115254 10116345
Revolution-dependent lubrication duration
I 1 - 16** 10115263 10116348
II 10 - 160** 10115273 10116351
III 170 - 320** 10115282 10116352
* pulses ** revolutions
Within a setting range, the lubrication duration and the cycle duration can be changed at the grid switches in the
inspection window of the protective housing (see fig. 40) using a flat screwdriver
For this, remove the frame at the inspection window of the protective housing using a flat screwdriver, loosen the four
cross point screws and remove the transparent inspection window.
After setting the parameters, the inspection window and the frame have to be closed properly
Caution!
again; otherwise

9.2.3 Operational mode of time-dependent cycle duration

At the operational mode of time dependent cycle duration, the cycle duration can be set in hours or minutes, depending
on the selected setting range. The setting range can be changed using the diagnosis software
current version available at www.beka-lube.de
Fig. 41:
Lubrication duration
Time-dependent
cycle duration
(with the current version available at
1 - 16 min 2 - 32 min 2 - 32 h
10115219 10115220 10115221 10115222 10115223 10115224
10115228 10115229 10115230 10115231 10115232 10115233
10116328 10116331 10116332 10116334 10116335 10116336
10115238 10115239 10115240 10115241 10115242 10115243
10115247 10115248 10115249 10115250 10115251 10115252
10115255 10115256 10115257 10115258 10115259 10115260
10115266 10115267 10115268 10115269 10115270 10115271
10115274 10115275 10115276 10115277 10115278 10115280
10115284 10115285 10115286 10115287 10115288 10115290
water can enter into the integrated control unit and can
-
).
...a product of
www.beka-lube.de
Pulse-dependent cycle duration
1 - 16* 10 - 160*
41
).
20 - 320* 100 - 1600* 500 - 8000*
10115225
10115234
10116338
10115245
10115253
10115261
10115272
10115281
10115291
destroy it!
BEKA-DiSys (with the
