7.2.1 Initial filling of devices with follow-up piston

Use a standard grease pump (hand lever grease gun) for the initial filling of the device with follow-up piston and fill the
device via the cone-type zerk.
Pay attention to utmost cleanliness at the initial filling of the device. Only fill in clean lubricant. When
dirt particles get into the device, the pistons of the pump elements can wear, which results in the
Caution!
destruction of the pump elements. The dirt particles can also get into the lubrication system and can
clog lines or connected progressive distributors.
A) Connect the device according to the connection diagram (see chapter 6.2 „Power connection") and turn it around
so that the reservoir cover points down (see fig. 9).
Fig. 9:
Overfill protection
B) Remove the overfill protection and the protective cap of the cone-type zerk (see fig. 10).
Fig. 10:
Overfill protection removed!
© BEKA 201 All 9 rights reserved
...a product of
!
Cone-type zerk with
protective cap
Protective cap removed!
16
